DART DA31837111 LS Next Cast Iron Engine Block 4.000" Bore 9.240" Deck HEIght

DART DA31837111 LS Next Cast Iron Engine Block 4.000" Bore 9.240" Deck HEIght

DA31837111
$5,596.60 AUD
$5,596.60 AUD
Sale Sold out
Tax included. Shipping calculated at checkout.



DART LS NEXT CAST IRON ENGINE BLOCK 4.000" BORE 9.240" DECK HEIGHT DA31837111



Dart's LS Next block is the first significant change in the architecture of the LS engine platform. By eliminating the “Y-block" design and utilizing conventional style main caps and oil pans, Dart has addressed the problems resulting from the LS engine's separated crankcase bays. Windage is greatly reduced, resulting in increased power along with a much stronger main web area.Features:
  • Dart's LS Next block is cast in the USA with premium cast iron alloy
  • Conventional style 4-bolt steel main caps with 7/16" bolts are used
  • Full main webbing for maximum bottom end strength
  • Cylinder barrels are extended by .375" at the bottom, providing greater piston support for all combinations
  • 9.240" deck height, with options of 9.450" are available which allows for a possible effective barrel length of 9.825" deck block
  • Extra thick Siamese cylinder bores allow for large displacement capacity, and a max bore size of at least 4.200"
  • A 5/8" thick full deck design with a 9.240" deck height
  • Six head bolts per cylinder provide secure clamping for power adder applications
  • Head bolts are upgraded to 7/16" for increased strength
  • Blind head bolt holes don't go through into the water jacket
  • Provision for oil restrictors in the lifter valley
  • Revised low restriction priority main oiling system
  • Pro-Stock / Pro-Mod big block style stepped main oil galley
  • An external oil filter must be used with stock or aftermarket oil pumps
  • Dual starter mounts
  • The water jacket on the #1 cylinder has been expanded for additional cooling capacity
  • LSX style lifter bosses and dog bone provision are provided

Specs:Application: Chevy small block Gen III/IV V8Main Journal Type:LS mains

Engine Block Style:Stock/OEM standard deck
Deck Height (in):9.240 in.
Cylinder Bore as Shipped:4.000 in.
Cylinder Bore Diameter:4.000 in.
Engine Block Material:Cast iron
Main Caps Included:Yes
Main Cap Material:Steel
Main Cap Fasteners Included:Yes
Main Bearings Included:No
Rear Main Seal Style:1-piece
Finished Cylinder Bores:No
Raised Cam Location:No
Cam Bearings Included:No
Freeze Plugs Included:Yes
Quantity:Sold individually.
Notes:Block bores are .10 undersized to allow for piston set up.














Manufacturer Part Number:
